Composite Beam Design to Eurocode 4









Composite beam design



ConSteel is capable of single as well as continuous span composite beam design in accordance with
Eurocode 4). Partial and full shear connection can be also designed.





Main features:
Composite beam definition with profiled sheeting or with solid concrete slab
Automatic calculation of effective width
Cracked and uncracked analysis
Option for moment redistribution
Design resistance calculation for bending, shear, bending and shear interaction, shear buckling, shear stud, longitudinal shear, crushing of concrete flange
Automatic calculation of the optimal number and layout of shear studs for partial shear (if possible) and also for full shear connection
Clear and straightforward results using exactly the same symbols as in EuroCode
GSS cross-section model for precise section properties and elastic stresses
Download

http://s18.alxa.net/s18/srvs2/01/Com...Eurocode.4.rar
