Engineering Spreadsheet, Software
Single and Continuous Beam Analysis
Single and Continuous Beam Analysis” is a spreadsheet program written in MS-Excel for the purpose of analysis of either single-span or continuous-span beams subjected to virtually any type of loading configuration. Four (4) types of single-span beams and two (2) through (5) span, continuous-span beams, considered. Specifically, beam end reactions as well as the maximum moments and deflections are calculated. Plots of both the shear and moment diagrams are produced, as well as a tabulation of the shear, moment, slope, and deflection for the beam or each individual span. Also, for steel single-span beams an AISC 9th Edition (ASD) Code check can be performed for X-axis bending and shear.
Download
http://s18.alxa.net/s18/srvs2/02/002...M.ANALYSIS.rar
