    Analysis of Weld Group” is a spreadsheet program written in MS-Excel for the purpose of analysis of weld groups using either the ultimate strength method (also known as “instantaneous center of rotation” method) or the “elastic” (vector) method (“Alternate Method 1″ in AISC Manual). A separate worksheet contains data tables for welds.Content
    Weld group instantaneous center analysis for vertical parallel welds
    Weld group instantaneous center analysis for horizontal parallel welds
    Weld group instantaneous center analysis for vertical rectangular welds
    Weld group instantaneous center analysis for horizontal rectangular welds
    Weld group instantaneous center analysis for C-shaped welds (case 1)
    Weld group instantaneous center analysis for C-shaped welds (case 2)
    Weld group instantaneous center analysis for L-shaped welds (case1)
    Weld group instantaneous center analysis for L-shaped welds (case 2)
    Weld group elastic analysis for up to 24 total weld lines and 4 load points
    Fillet Weld Data Tables
