nanoSoft nanoCAD Electro v11.0.5093.5093
nanoCAD Electro - computer-aided design in terms of power electrical equipment (EM), internal (EA) and external (EN) electric lighting of industrial and civilian facilities.
Elements in the equipment database contain all the necessary information, starting with the name and ending with the 3D model. The databases of nanoCAD Electro equipment are fully open for editing and updating. The program provides free databases for all manufacturers of electrical equipment that have partnerships with Nanosoft.
The program contains an extensive list of model checks for correct execution. If any element of the model deviates from the standards, the program signals this to the user.
The nanoCAD Electro system relieves the design engineer from laborious routine work: marking equipment, performing calculations, counting all equipment, products, materials and listing them into specifications, compiling a cable magazine, creating network diagrams and much more. At the same time, the risk of errors in the design documentation due to the “human factor” is minimized. As a result, the design process is noticeably accelerated, and the quality of documents is growing.
In nanoCAD Electro it is possible to form cable routes of any complexity: single-tiered and multi-tiered, single-sided and double-sided. The program automatically selects connectors up to nuts and bolts if the equipment database is sufficiently detailed. The program automatically calculates the cable lengths taking into account all the specifics: the cable reserve for laying, the cable reserve for cutting, rounding the cable length to a predetermined value, and so on. In addition, for power cables, the program automatically determines the required number of cores.
NanoCAD Electro implements both methods of calculating illumination: the coefficient of utilization and the point method. After the calculation using the coefficient of utilization, the program automatically arranges the fixtures in the room.
In nanoCAD Electro all the necessary electrical engineering calculations are implemented:
Calculation of electrical loads according to RTM 36.18.32.4-92, SP 256.1325800.2016 and TEP
Calculation of currents of one-, two- and three-phase short circuits according to GOST 28249-93 and “Phase-zero loop”
Calculation of cable for non-ignition according to Circular No. Ts-02-98 (E)
Calculation of leakage currents through insulation according to PUE 7 p. 7.1.83
Voltage drop calculation
Based on the results of work in nanoCAD Electro, the following project documents are generated:
plans for the location of equipment and laying cable routes;
schematic diagrams of distribution and supply networks;
specification of equipment, products and materials;
cable magazine;
reports with the results of lighting calculations;
reports with the results of electrical calculations.
3.21GB
Download
http://s15.alxa.net/002/001/nanoSoft....5093.5093.rar
