DLUBAL COMPOSITE BEAM 8.31.01 (rev.23012023) x64
Dlubal Software has released 8.09.01 version of COMPOSITE-BEAM. This software analyzes continuous composite girders according to Eurocode 4. This add-on module can be used with the RSTAB program or also as an independent module that runs on RSTAB standards.
The structure and load input in this module is done through clearly laid out masks like those found in RSTAB.
When the analysis is started, the static model is generated in RSTAB with all boundary conditions and loads. Consequently, a safe calculation of the internal forces using the ideal cross-section properties is guaranteed.
COMPOSITE-BEAM automatically analyzes the resulting internal forces and carries out all relevant verification according to EC 4 and following the standards in EC 2 and EC 3.
The results are displayed in the spreadsheet masks.
They are sorted by the required analysis standards and thus enable an easy orientation.
The user`s control over the input as well as the interpretation of the results is facilitated through 3D visualization.
All graphics can be edited and transferred to the Printout Report.
Since its beginnings in 1987, the Dlubal company has been involved in the development of user-friendly and powerful software for structural and dynamic analysis.
With RSTAB and RFEM Dlubal offers programs for the ambitious structural engineer that meets the requirements of modern civil engineering and mirrors the current state of art.
RSTAB is a 3D framework program, while RFEM represents a 3D Finite Element Analysis (FEA) program.
Both are the basis of a modular software system:
This basic module calculates internal forces, deformations and support reactions.
For the following design, add-on modules are available which account for the specific requirements of materials and codes.
Due to this modular conception of the software, a package can be assembled that is tailored to individual demands.
Product: Dlubal COMPOSITE-BEAM
Version: 8.x
Supported Architectures: x64
Website Home Page : dlubal.com
Language: multilanguage
System Requirements: PC
Supported Operating Systems: Windows 7even / 8.x / 10
Size: 675 mb
Note: The program is based on bidirectional communication between RSTAB and the add‑on modules. However, an RSTAB license is not required for using COMPOSITE‑BEAM (stand‑alone operation is possible).
Download
*
