NUMECA HEXPRESS/Hybrid 10.1 Win/Linux x64
The HEXPRESSTM / Hybrid program appeared on the market as a response to the need of European automotive companies for a fast and efficient mesher (grid builder), with which you can build computational grids for complex topologies in an extremely short time. At the moment, in our opinion, this is the only known tool that allows you to build a grid for calculating both the external and internal aerodynamics of such a complex object as, for example, a car, including the engine compartment and the interior, in one day, starting directly from the “unclean” geometry.
HEXPRESSTM / Hybrid offers its meshing technology and its original meshing approach. The preprocessing is divided into two stages, the first is working with geometry in the user interface of the program. The second stage is the launch of building a grid from the command line (in the style of working with Linux, Unix operating systems) using a text configuration file that contains the parameters of the meshing. There are few options for meshing, they are intuitive. The main advantage of combining the GUI philosophy and working on the command line using the configuration file is the speed and automatism in rebuilding grids, the process of creating new grids for new standard geometries is accelerated many times, bypassing the often tedious stage of grid setup in the user interface (you already have there is a ready-made config file and everything you need
The meshing process in HEXPRESSTM / Hybrid is completely parallelized; by default, it runs on all available parallel computer processor cores.
Unique innovative technologies embedded in HEXPRESSTM / Hybrid allow you to automatically build hexadominant, conformal grids (it is possible to build tetra or full hex grids) for the entire settlement domain or several domains, the grid is built with the resolution of the wall layer or without it, if desired.
The key feature of the HEXPRESSTM / Hybrid is that it is not demanding on the cleanliness of the initial geometry and can build a grid for geometries with serious flaws, crevices, etc., which generally reduces the time step of meshing by an order of magnitude when working with real, "unclean" geometries .
HEXPRESSTM / Hybrid has a built-in automatic tool for finding and closing holes, which allows you to start working with almost any geometry that you have been transferred without having the deep knowledge or time to solve the problem in CAD or similar systems.
HEXPRESSTM / Hybrid is an ideal tool for building grids of large dimension, complex geometry topology in the shortest possible time.
Currently, HEXPRESSTM / Hybrid has found its fans in almost all branches of engineering and industry, including such atypical areas as medicine.
File Size: 2.98 GB
Download attachment
