CSI XRevit 2022.1.0 x64

CSiXRevit is a plugin for Autodesk® Revit® that enables bi-directional data transfer to CSI Software products: SAP2000® , ETABS® and SAFE®.



Users have full control over what model data gets transferred and how that data gets mapped to equivalent objects in either software.
CSiXRevitTM requires its own license to run.
Structural modeling can be done in ETABS®, SAP2000® or SAFE® or in Revit® and then later be synched up.

Supported Workflows
CSiXRevit supports four (4) main workflows of data transfer with Revit:
Exporting from Revit to create a new CSI Software model
Exporting from Revit to update an existing CSI Software model
Importing from CSI Software to create a new Revit Model
Importing from CSI Software to update an existing Revit Model

Data Transfer
The user has full control over what model information will be transferred between CSI Software models and Revit models.

Intermediate Data Exchange
All CSI products use the same intermediate data exchange file (.exr) to control model data exchange.

Parametric Mapping
CSiXRevit will support both direct section mapping of standard steel sections and also parametric sections that have been defined in Revit.

CSiXRevit v2022.1.0 is now available for use with Revit® 2022.1. CSiXRevit v2022.0.0 is compatible with Revit 2022.0.


Size: 119 MB
