BobCAD-CAM v36 build 5009 x64


BobCAD-CAM’s Version 36 release has brought with it some incredibly powerful tools to add to your CAD-CAM arsenal. We have made some amazing improvements on geometry selection, how to program your part, and now, even give you a Toolpath Editor to give you the control to edit anything you want about the whole operation, a portion of the operation, or even a single entity of the overall operation.




CAD PICKING
Updates have been made to many of the CAD functions that require the selection of other geometry.
Many of the CAD functions require picking other geometry to perform the function; Subtract this from that, or, use this as my Attachment Point, this as my Sweep Profile, and this as my Sweep path are examples.

In either case, the order of the selections plays a big role in the result, and, in the past, getting the order wrong would usually result in canceling the function and reopening the function, just to try again.
With our new and improved interface, we have eliminated these issues with list boxes for the selected geometry.

These list boxes have controls to delete geometry or even reverse chains and adjust the order of the selected geometry when necessary. This gives you an unprecedented amount of control over selection of geometry and the result of the function.

The Sweep and Cross Section functions are used as examples below.
One of the huge benefits of the new selection aspect of these functions is being able to try different things to see how they affect the preview of the result before finalizing.
The Sweep function, for instance, will give different results depending on the Attachment Point being used.

With the new selection functionality, you could pick the Attachment Point, Sweep Profile, and Sweep Path to see the Preview, and then, delete only the Attachment Point, in order to pick a different Attachment Point to test another result.

The functions with updated picking are as follow
Surfaces- Planar, Extrude Curve, Extrude Surface, Revolve, Sweep, Cross Section, Skin, Offset, 3 Edge, 4 Edge, Multisided Patch, Fillet, Intersection Curves, Break Surface, Swung, Ruled
Solids- Fillet, Add, Subtract, Intersect, Extrude Boss, Extrude Cut, Split, Shell, Imprint

SCALE SKETCH HANDLE
The Translate function has a handy new feature to use when scaling.
In some cases, scaling is needed without a specific value in mind, an adjustment for aesthetics for instance.
It is in cases like these, entering different scale values and checking the resulting preview can be a little frustrating, and in situations like these, the Scale Sketch Handle is the perfect solution.
Simply click on the scale sketch handle and drag your mouse to adjust the scale where you want it. Click again to set the scale value.

System Requirements
Operating System: Windows 10 x64 or later
CPU: 2.0 GHz multi-core processor or higher
Memory: 6 GB RAM or higher
Available Hard Disk Storage: 2 GB or higher
Video: 1 GB *graphics card that supports OpenGL 1.1


Size: 1.17 GB
