Fanuc CNC GUIDE 25.0 Multilingual
CNC GUIDE provides all the operating features and control, as well as the ability to run and simulate Programmable Machine Controller (PMC) for development and debugging of C Language Executor, Macro Executor and FANUC PICTURE PROGRAM and integration of FOCAS2 application functions
Virtual panel control displays input status and output signals which, when used with PMC FANUC LADDER III programming software, means the engineer can write and test machine logic sequences "on the bench".
You can link CNC GUIDE with other FANUC PC software such as: Program Transfer Tool, CNC Setting Tool and FANUC Built-in 3D Interference Check Setting Tool.
CNC GUIDE supports a parameter tuning tool that automatically finds the optimal parameters for acceleration and deceleration. This reduces parameter setup time and allows setup to be done without occupying the actual machine.
I express my immense gratitude to forum user cccp3d.ru Victor for providing the program.
The distribution also contains an example of working with the PMC simulator, kindly posted by one of the users of the cccp3d.ru forum
Add. information : Treatment: after installing the program, copy and replace the contents of the folder "NcGuidePatch25-FANUC" to the folders of the installed program in Program Files (x86)\FANUC
System requirements : OS Microsoft Windows 8.1 Professional (32bit, 64bit), Windows 10 (32 bit, 64 bit), .NET Framework 3.5
CPU Pentium® 4, 2.8GHz or more, Intel Core Duo 1.83GHz or higher (Core 2 Duo, Core i3,
Core i5, Core i7 in case of Cycle Time Estimate Function)
Main memory 2 GB RAM or more
Hard disk 8 GB or more
Screen resolution 1280 x 1024 (or higher)
1920 x 1080 recommended
File Size: 4.17 GB
Download
*
