Concise Beam 4.66.6.0
Concise Beam V4 is an easy to use program for the design of precast concrete beams.
Concise Beam will perform a load analysis and design checks in accordance with the latest edition of ACI 318, CSA A23.3 & S6, AS3600, or NZ3101.1.
Key code parameters can be customized to simulate other design codes.
The beam can be conventionally reinforced, partially or fully pretensioned.
It can model any cross-sectional shape and will allow the cross-section to vary prismatically (step-wise) over the length of the beam.
A graphical editor allows the user to describe any cross-section, including voids.
Concise Beam works in two-dimensions using simple beam theory (ACI B-region) but will also account for torsion along the beam.
Concise Beam is NOT able to perform any analysis or design checks required for disturbed regions (ACI D-region) such as at sudden changes in section, large openings, notches, or dapped ends.
The user can work in metric or U.S.
Customary (Imperial) units, with a variety of individual units (i.e. mm, cm, m), and switch back and forth at will.
Libraries of industry standard cross-sections and materials are provided with Concise Beam.
The standard libraries can be modified, extended and customized by the user.
Beam Layouts
Single simply-supported beam
Cantilevers at one or both ends
Analyze any user defined cross-section
All standardized loads, load cases, and combinations
Moving Loads, including highway live loads
Load distribution (including PCI hollowcore distribution)
Cast-in-place pour (topping or deck) definition with haunch
Shoring of Cast-in-place pour (point or continuous)
File size: 22 MB
Download
