GstarCAD Mechanical 2024 Build 20240403 (x64)
Covering all fields of mechanical design, GstarCAD Mechanical is professional designing and drawing software specially built for manufacturing. No matter what kind of design task you are facing, GstarCAD Mechanical helps to complete your ideas perfectly.
Features
Compatible with ACM
GstarCAD Mechanical supports bidirectional data exchange of ACM that other CAD doesn't.
Users can modify ACM data and send them back to ACM. Based on smooth data transfer and high compatibility, mixed-use with ACM become a reality.
Dynamic input
Dynamic Input provides a command interface near the cursor to help you keep your focus in the drafting area. Save time typing and finding out whatever longer or shorter command. Dynamic input can autocomplete the command name at once.
Property and Tool Palette
Properties palette displays the properties of the selected object or set of objects. You can specify a new value to modify any property that can be changed. Tool palette provides an efficient method for organizing and placing blocks.
Reasonable Price
By keep exploring the balance between practicality, ease-of-use, and compatibility with ACM, GstarCAD Mechanical offers convenient and concise functions at a walt-friendly price.
Users can complete same design with a more cost-effective solution.
Layer Properties Manager & Layer States Manager
Layer properties manager displays a list of the layers in the drawing and their properties. You can add, delete, and rename layers, change their properties, set property overrides for layout viewports, or add layer descriptions and apply changes in real time.
Layer states manager enables you save the current property settings for layers in a named layer state and then restore those settings later.
Command Line
-You can enter a command by using the keyboard. You can also repeat the previous command by pressing Enter or Spacebar without entering a command.
Clean Screen
-If you want to maximize drawing space, you can press "CTRL+0" or click Clean Screen icon on the right of status bar to hide Toolbars, Windows or Ribbon.
File Tabs
-File tabs offer a fast way to switch the opening-drawings, and you can change the opening-order by draging tabs. It also has built in functionalty like save, close, audit and properties.
Lock UI
-Lock the position of toolbar/window. The lock icon in the status bar indicates whether Toolbar/Window is locked. Click the icon to display locking options.
System Requirements
OS:Windows Windows 10 (x86-x64)
CPU:1GHZ or faster, 32-bit(x86) or 64-bit(x64) processor
Memory:32-bit 3GB recommended or higher) /64-bit 4GB recommended or higher)
Display:1024 * 768 VGA with True Color (minimum)
Space:1GB free hard disk available or higher(3GB recommended or higher)
x64 | Languages:English | File Size: 315 MB
Download
http://s9.alxa.net/one/2024/10/Gstar...N_20240403.rar
