InMotion Consulting IMGeneral Solutions 2024.1.1.2

MGeneral Solutions provides simple, key tools needed to make every user more productive.




The tools are divided into
Block Tools

Polyline Tools
Management Tools
Miscellaneous Tools
Block Tools

Rotate By Insertion Point: Rotates All Selected Objects Around Their Insertion Point by a Specified Value
Attribute Counter: Adds the number of the selected blocks found in the text of a selected Attribute tag
Align Objects: Aligns Blocks and text to Lines, Arcs, and Polylines
Polyline Tools

Set Polyline Width: Sets the Global Width for all selected objects. If the object selected is not a polyline, the function will convert it into one
Set Elevation: Sets the Z elevation for all selected objects.
Management Tools

Import Blocks: Imports all the blocks from the selected drawings. Overwrites any existing.
Import Text Styles: Imports all the text styles from selected drawings. Overwrites any existing.
Import Layers: Imports all the layers from the selected drawing. Overwrites any existing.
Import Dimension Styles: Imports all the dimension styles from selected drawings. Overwrites any existing.
Import Linetypes: Imports all the linetypes from the selected drawing. Overwrites any existing.
Import Views: Imports selected Model Space Views from the selected drawing
Rename Blocks: Renames all selected blocks
Rename Layers: Renames all selected layers
Save Scale List: Saves the current drawing’s Annotation Scales to an external file
Edit Scale List: Edits an existing annotation scale list file
Update Scale List: Updates the current drawing’s annotation scales
Miscellaneous Tools

Create Line Tangent to Arc: Adds a Line Tangent to the Picked Point Along the Selected Arc
Create Perpendicular Line: Creates a line of specified length perpendicular to the point picked from the selected object
Copy Along Path: Copies and aligns the selected object along a selected path
Set Viewport Angle: Twists the Viewport’s Rotation Angle by the specified amount. Rotates any Paper Space North Arrow Blocks Selected also
Align Crosshair: Sets the Crosshairs to be Aligned to the Current View’s Twist Angle
Offset To Layer: Offsets selected objects, then select the layer for offset objects
Multiple Offset: Offsets a selected object multiple times in a specified direction
Offset Text Object: The Offset Text Object function ‘nudges’ a Text or Mtext object a specified distance in a specified direction.
Offset Nested Object: Offsets Object Nested in a Block or Xref
Get Distance At Point: Measures the distance along with the selected object to a specified point
Measure Distance of Objects: Measures the length of all selected objects and provides the total

Compatible with
Autodesk AutoCAD
Version: 2024 , 2023 , 2022 , 2021 , 2020
Autodesk AutoCAD Electrical
Version: 2024 , 2023 , 2022 , 2021 , 2020
Autodesk AutoCAD Mechanical
Version: 2024 , 2023 , 2022 , 2021 , 2020
Autodesk AutoCAD Architecture
Version: 2024 , 2023 , 2022 , 2021 , 2020
Autodesk AutoCAD MEP
Version: 2024 , 2023 , 2022 , 2021 , 2020
Autodesk® Civil 3D®
Version: 2024 , 2023 , 2022 , 2021 , 2020
Autodesk AutoCAD Map 3D
Version: 2024 , 2023 , 2022 , 2021 , 2020


File Size: 2.4 MB
