Canadian Wood Council WoodWorks Design Office USA Edition v11.1 SR-1
With WoodWorks Sizer, you can size beams, joists, columns and wall studs to meet the 2015 National Design Specification (NDS) for Wood Construction.
Specify dead, live, snow and wind loads
Automatically pattern loads
Generate a materials take-off summary based on your design
Design for point, line, area, triangular, and trapezoidal loads simultaneously
Automatically check all load combinations as per IBC 2015, ASCE 7-10
Analyze the critical load cases for reactions at supports, shear, bending, and deflection
Generate detailed analysis reports and diagrams
Generate a list of acceptable sections for dimension lumber, heavy timbers, glulam, LVL, or I-joists
Use the Materials Database editor to customize the software to your needs
Design Entire Structures – Concept Mode
Configure and design a complete structure in plan
Do preliminary designs of structures considering gravity loads using the graphical design and analysis work area
Perform multi-storey gravity load analysis – sizing all structural members and reporting the reactions at the base
Export elements from Concept Mode for further analysis into either Beam Mode or Column Mode
Design Beams – Beam Mode
Design individual wood bending members
Use Beam Mode to verify the design of critical bending members
Generate deflection, shear and bending moment diagrams for any beam or joist in your project
Design single or multi-span beams and joists with or without cantilevers
Design beams for gravity and uplift loads
Specify full, clear or design span
Design supporting members for bearing
Design Beams with end and interior notches
Design Columns – Column Mode
Design individual wood columns, walls, and beam-columns
Use Column Mode to verify the design of critical compression members
Design columns and wall studs to resist both axial and lateral loads
Generate deflection, shear and bending moment diagrams for a single column or wall stud
Check wall bottom plate for bearing
Shearwalls
With WoodWorks Shearwalls, you can perform complete shearwall design and lateral load analysis.
Design shearwalls for multi-storey and irregularly shaped buildings
Determine hold-down and drag-strut forces and display them graphically
Design shearwalls with or without hold-downs
Generate an elevation view to show loads and forces on each shearwall
Assign loads to shearlines following a flexible or rigid diaphragm analysis
Import Adobe PDF and CAD (.wmf) files to establish the building footprint
Model wood structures up to six stories
Specify openings in shearwalls such as windows and doors
Model roof shapes, including hips, valleys, gables, and overhangs
Quickly assess the locations of high aspect ratio segments in a structure
Wind Load Generation
Generate wind pressure and resulting lateral loads as per ASCE 7-10
Input specific site information, including wind speed up over a hill
Manually input lateral loads or modify wind loads that were automatically generated
Report shearwall material designs for all wind load cases
Check the capacity of wall sheathing and nailing to resist wind suction (components and cladding loads)
Check shearwalls for wind serviceability deflection and story drift
Seismic Load Generation
Generate seismic loads as per the IBC 2015 (ASCE 7-10)
Input site-specific seismic information
Manually input lateral loads or modify seismic loads that were automatically generated
Report shearwall material designs for all seismic load cases
Connections
With WoodWorks Connections, you can design new connections or check the capacity of existing ones.
Produce fully dimensioned, CAD-quality drawings
Generate a material list for fasteners and steel plates
Run designs using lag screws, wood screws, bolts, nails, shear plates or top-mount hangers
Post & Beam Connections
Design connectors for beam-to-beam, beam-to-column, and column-to-foundation connections
Allows output of beam-to- beam connections as .dxf files for use in AutoCAD
Lapped Shear Connections
Design single or double shear connections for wood-to-wood, wood-to-steel, and wood-to-concrete configurations
Size: 106 MB
Download
http://s15.alxa.net/001/007/CWC.Wood...v11.1.SR-1.rar
